How to Install Stock ROM on Motorola XT2125-4 (Firmware Guide)

On this page, we have shared the download link and guide to install the Motorola XT2125-4 (Motorola Edge S, codenamed nio) firmware flash file using the fastboot method. Here you will find all stock firmware zip files for all the supported regions with Motorola Edge S XT2125-4.

If you are someone who wants to restore the device back to factory firmware, then this guide is for you. By using this guide, you can fix certain software-related issues such as hard brick, soft brick, WiFi, or Bluetooth issue, fix lag or stutter or even you can downgrade the device anytime.

How to Install Stock ROM on Motorola XT2125-4 (Firmware Guide)

Steps to Install Motorola XT2125-4 Stock Firmware

Now, if you’re ready to flash the stock firmware manually on your Motorola Edge S XT2125-4 (nio) device then you need to download the flash tool, firmware file, and necessary drivers. So, without wasting any more time, let’s get into it.

Pre-Requirements:

Disclaimer:

GetDroidTips will not be held responsible for any kind of hardware or software damage to your device by following this guide. Proceed at your own risk

Motorola Edge S XT2125-4 Firmware Flash Files:

Flash File Name: S1RTS32.41-20-16-1-3
Model: XT2125-4
Android Version: Android 12
Download
Flash File Name: S1RTS32.41-20-16-1-2
Model: XT2125-4
Android Version: Android 12
Download
Flash File Name: RRTS31.Q1-20-14-2
Model: XT2125-4
Android Version: Android 11
Download

Firmware Installation Guide:

Check out the firmware flashing guide below for the Motorola Edge S XT2125-4 (nio). First, make sure to install or extract the adb and fastboot tool on your PC. Now enter the bootloader on your device.

bootloader mode

Step 1. Bootloader Mode

Enter bootloader mode on your phone. To boot first, turn your phone off. Once your device turned off completely, press and hold volume down, and turn it on. You should see the bootloader screen.

Step 2. Connect Your Device to PC:

After booting your Motorola Edge S into bootloader mode, now connect it to the PC using the USB Cable.

Step 3. Download Stock ROM/Firmware:

To get the full ROM, you can use the LMSA or Rescue and Smart Assistant Tool. Download the zip file and copy it to somewhere on your PC. LMSA tool will unzip the file and will remove the zip file you downloaded.

device rescue Motorola Rescue and Smart Assistant Tool

You can also download the full stock ROM from the above download flash file section on this guide.

Step 4. Flashing Guide:

  1. The next step is to open the command window and go to the adb folder Open Command Window here
  2. Enter the following command to flash the firmware.
    fastboot flash partition gpt.bin
    fastboot flash bootloader bootloader.img
    fastboot flash vbmeta_system vbmeta_system.img
    fastboot flash radio radio.img
    fastboot flash bluetooth BTFM.bin
    fastboot flash dsp dspso.bin
    fastboot flash logo logo.bin
    fastboot flash boot boot.img
    fastboot flash vendor_boot vendor_boot.img
    fastboot flash dtbo dtbo.img
    fastboot flash super super.img_sparsechunk.0
    fastboot flash super super.img_sparsechunk.1
    fastboot flash super super.img_sparsechunk.2
    fastboot flash super super.img_sparsechunk.3
    fastboot flash super super.img_sparsechunk.4
    fastboot flash super super.img_sparsechunk.5
    fastboot flash super super.img_sparsechunk.6
    fastboot flash super super.img_sparsechunk.7
    fastboot flash super super.img_sparsechunk.8
    fastboot flash super super.img_sparsechunk.9
    fastboot erase userdata
    fastboot erase ddr
    fastboot oem fb_mode_clear
    fastboot reboot
  3. Now your device will reboot into bootloader with the firmware you installed.

That’s it, guys. We hope this guide was helpful to you. Feel free to ask in the comment below for additional queries.
