In this tutorial, we will guide you on how to install the TWRP Recovery on Samsung Galaxy S23 Ultra (dm3q). TWRP recovery is probably the most used and most popular custom recovery that we all know. Those who are quite accustomed to rooting and flashing custom ROM, etc. then, know what TWRP Recovery is. However, for naive, the TWRP Recovery allows users to install custom ROMs/mods, take a complete backup of their phone, and gain root access on their phone using Magisk Manager.
However, you are required to have TWRP access before you can go ahead and root your Samsung Galaxy S23 Ultra. For flashing the TWRP recovery image, you need to follow the guide properly to avoid errors. And if you happen to own a Samsung Galaxy S23 Ultra and are looking for ways to download and install the TWRP Recovery on your phone then, you are at the right place as in this post, and we will guide you on how to download and install TWRP Recovery on Samsung Galaxy S23 Ultra and eventually root using Magisk. So, that being said, let us get straight into the article itself:
- Samsung Galaxy S23 Ultra Device Overview:
- What is TWRP Recovery?
- Steps to Install TWRP Recovery on Galaxy S23 Ultra (dm3q)
- Instructions to Install TWRP
- Root Samsung Galaxy S23 Ultra Using Magisk
Samsung Galaxy S23 Ultra Device Overview:
The Samsung Galaxy S23 Ultra features a 6.8 inches Dynamic AMOLED panel with a 120 Hz refresh rate and HDR10+ compatibility. It is an FHD+ panel with a resolution of 1440 x 3088 pixels and an aspect ratio of 19.5:9. The screen has a peak brightness of 1750 nits and in terms of protection we get Gorilla Glass Victus 2 protection on both the front and the back panel. Under the hood, we get the Qualcomm Snapdragon 8 Gen 2 processor built on a 4 nm manufacturing process. It is an octa-core processor with one Cortex-X3 core clocked at 3.36 GHz, two Cortex-A715 cores clocked at 2.8 GHz, two Cortex-A710 cores clocked at 2.8 GHz, and three Cortex-A510 cores clocked at 2.0 GHz. For handling the graphics-intensive tasks, we have the Adreno 740. The smartphone comes with Android 13 out of the box with One UI 5.1 skin running on top.
In terms of optics, we get a quad camera setup at the rear and a single selfie camera at the front. The rear camera setup consists of a 200MP primary sensory paired with f/1.7 lens, a 10MP periscope telephoto sensor paired with an f/4.9 lens, a 10 MP telephoto sensor paired with an f/2.4 lens, and a 12 MP ultrawide sensor paired with an f/2.2 lens. The selfie camera at the front is a 12 MP primary sensor paired with an f/2.2 lens. The rear camera setup can capture 8K videos at 24/30fps, while the front camera is limited to 4K video recording at 30/60 fps.
The smartphone comes in two storage options: 256GB internal storage + 8GB RAM, 256GB RAM + 12GB RAM, 512GB + 12GB RAM, and 1TB internal storage + 12GB RAM. We do not get a dedicated microSD slot for storage expansion. In terms of communications, we get Wi-Fi 802.11 b/g/n/ac/6e, Bluetooth 5.3, GPS, NFC and micro USB Type-C 3.2. And for sensors, we get an under-display ultrasonic fingerprint sensor, accelerometer, gyro, proximity, compass, and barometer. Powering it all is a 5000 mAh battery that supports 45W fast charging. The smartphone has eight colour options: Phantom Black, Green, Cream, Lavender, Graphite, Sky Blue, Lime, and Red.
What is TWRP Recovery?
Team Win Recovery Project or TWRP Recovery is a useful and popular custom recovery, which is open-source software. The touch-screen-enabled interface allows users to flash third-party firmware and back up the system or data easily like never before. For Android customization lovers or developers, a custom recovery is a much-needed tool or software.
Additionally, you can install the kernel, modules, root or unroot, take Nandroid backups, etc. Meanwhile, you can wipe system partitions, internal storage, data, cache, vendor, etc. very easily.
Advantages of TWRP Recovery
- Backups of partitions in TAR or raw Image format
- Restore backups from internal storage, external SD storage, or OTG devices
- Install Custom Firmware
- Install flashable ZIPs and image files
- Partition wiping
- Delete System, Cache, Vendor, Partition, User Data, etc
- Install Root or Unroot by flashing ZIPs
- Terminal access
- ADB Root Shell
- Theme Support
- Possible decryption support depending on the device
Steps to Install TWRP Recovery on Galaxy S23 Ultra (dm3q)
Now before we go ahead and install TWRP Recovery on the Samsung Galaxy S23 Ultra, let us make a list of pre-requisites that are required to unlock it:
Charge your phone
You need to make sure that your Samsung Galaxy S23 Ultra is charged to about 60% before installing TWRP recovery to avoid any boot loop issues during the unlocking process.
Take a complete backup
Before rooting, one of the most important things that you need to do on your phone is to take a complete backup of your phone. For that, you can follow the guide by clicking the link below:
Activate Developer Options
To Enable the Developer Option on your device, follow the below steps:
- Go to the Settings menu of your Android device.
- Then scroll down and go to About.
- Now you need to head to Software Information>> More.
- Here tap on Build Number 7-8 times until you see a message “You are now a developer”.
You also need to enable USB Debugging and OEM unlock option under the Developer Options menu. And to do that:
- Head over to Developer Options and toggle ON the USB Debugging option as well as the OEM unlock option.
Install ODIN tool
You need to install the latest Odin tool on your PC. For that, you can follow the link mentioned below:
Unlock the bootloader
In order to install the TWRP Recovery, you have to first unlock the bootloader on the Samsung Galaxy S23 Ultra.
Download Samsung USB Drivers
You can follow the link in order to download the correct Samsung USB drivers for Windows and Mac.
Download TWRP Recovery
Here you will find the latest TWRP recovery for the Samsung Galaxy S23 Ultra.
|File Name||TWRP Recovery|
|Device Name:||Samsung Galaxy S23 Ultra|
Instructions to Install TWRP
Follow the step-by-step instructions mentioned below to simply install the TWRP Recovery on your Samsung Galaxy S23 Ultra:
- Once you have downloaded, reboot your device into download mode.
- Flash the vbmeta_disabled_R.tar in the USERDATA slot and click start.
- Now the device will boot into recovery mode prompting you to wipe data.
- Wipe data and reboot to download mode again
- Open Odin and add the TWRP Tar file in the AP slot and click start to flash.
- Once it is done, you can reboot to recovery via recovery key combo (Vol UP + Power button + USB connected).
- In your TWRP Recovery menu, disable encryption:
- Go to Advanced > Terminal, type:
- Go to Advanced > Terminal, type:
- If the vendor complains about free space left on the device, will attempt to resize the vendor. and it asks to
- Run multidisabler again!.
multidisableragain and you will see
- Finished.when done.
- Go back to Wipe > Format Data > type
You can check out our full-depth tutorial video as well:
- Once the device booted into TWRP Recovery mode, you need to decrypt the data partition. In order to do it: Go to Wipe > Format Data and follow the on-screen instructions.
- Then reboot to recovery mode again.
- Now, flash the Samsung multidisabler zip and then flash the DM Verity Force Disabler (To avoid some issues, like the Reboot thing)
- That’s it. Reboot to the system finally. Enjoy!
Root Samsung Galaxy S23 Ultra Using Magisk
- Now you need to install the Magisk Manager APK on your phone.
- Place it in the internal memory on your device.
- Then head over to recovery by pressing the Volume up + Power button together.
- Make sure you have created a backup of your Samsung Galaxy S23 Ultra.
- In TWRP, select Install and locate Magisk.zip and select the file.
- Swipe to Install and flash it.
- Restart your device.
So, there you have it from my side in this post. I hope you guys liked this post and were able to install the TWRP Recovery and root your Samsung Galaxy S23 Ultra smartphone. Let us know in the comments below if you faced any issues while installing the TWRP recovery on your phone and then rooting it using Magisk. Until the next post…Cheers!
