Want to install the stock firmware on your Motorola One? then you are in the right place. In this guide, we will help you in installing the official stock firmware on Motorola One (codenamed deen) variant XT1941-4. Stock firmware comes in handy when you mess up your device to root it or install a mod or custom ROM. To be on the safe side, we always ask our users to download the official firmware on their PC and save it.
By installing firmware flash file on Motorola One XT1941-4, you can unbrick, restore, fix any software related issue, downgrade or upgrade, resolve any bugs or lag on your device. To install the Motorola One XT1941-4 firmware, you need the ADB and Fastboot tool on your computer.
Page Contents
Motorola XT1941-4 Firmware Flash Files:
| Flash File Name: QPKS30.54-22-13-15 Model: XT1941-4 | RETIN | India Android Version: 10 |
Download |
| Flash File Name: QPKS30.54-22-13-15 Model: XT1941-4 | RETEU | Europe Android Version: 10 |
Download |
| Flash File Name: QPKS30.54-22-13-13 Model: XT1941-4 | RETEU | Europe Android Version: 10 |
Download |
| Flash File Name: QPKS30.54-22-13-12 Model: XT1941-4 | RETEU | Europe Android Version: 10 |
Download |
| Flash File Name: QPKS30.54-22-13-13 Model: XT1941-4 | RETIN | India Android Version: 10 |
Download |
| Flash File Name: QPKS30.54-22-13-4 Model: XT1941-4 | RETIN | India Android Version: 10 |
Download |
Steps to Install Motorola XT1941-4 Firmware Flash File
If you have downloaded the firmware, then follow this guide to flash the stock firmware manually on your Motorola One XT1941-4. Make sure to follow the steps carefully.
Pre-Requirements:
- This ROM is supported for the Motorola XT1941-4 (deen) variant only.
- Make sure that your device should be charged at least 50% or higher.
- You will require a PC or Laptop with a USB Data Cable.
- We always recommend our readers take a full data backup of the device for safety purposes.
- Install Motorola USB Drivers and Rescue and Smart Assistant Tool on your PC
- To flash, you must download the ADB and Fastboot tool
Disclaimer:
Firmware Installation Guide:
Check out the firmware flashing guide below for the Motorola One XT1941-4. First, make sure to install or extract the adb and fastboot tool on your PC. Now enter the bootloader on your device.
Step 1. Bootloader Mode
Enter bootloader mode on your phone. To boot first, turn your phone off. Once your device turned off completely, press and hold volume down, and turn it on. You should see the bootloader screen.
Step 2. Connect Your Device to PC:
After booting your Motorola One into bootloader mode, now connect it to the PC using the USB Cable.
Step 3. Download Stock ROM/Firmware:
To get the full ROM, you can use the LMSA or Rescue and Smart Assistant Tool. Download the zip file and copy it to somewhere on your PC. LMSA tool will unzip the file and will remove the zip file you downloaded.
You can also download the full stock ROM from the above download flash file section on this guide.
Step 4. Flashing Guide:
- The next step is to open the command window and go to the adb folder
- Enter the following command to flash the firmware.
fastboot oem fb_mode_set fastboot flash partition gpt.bin fastboot flash bootloader bootloader.img fastboot flash vbmeta vbmeta.img fastboot flash radio radio.img fastboot flash logo logo.bin fastboot flash boot boot.img fastboot flash dtbo dtbo.img fastboot flash recovery recovery.img fastboot flash super super.img_sparsechunk.0 fastboot flash super super.img_sparsechunk.1 fastboot flash super super.img_sparsechunk.2 fastboot flash super super.img_sparsechunk.3 fastboot flash super super.img_sparsechunk.4 fastboot flash super super.img_sparsechunk.5 fastboot flash super super.img_sparsechunk.6 fastboot flash super super.img_sparsechunk.7 fastboot flash super super.img_sparsechunk.8 fastboot flash super super.img_sparsechunk.9 fastboot flash super super.img_sparsechunk.10 fastboot flash super super.img_sparsechunk.11 fastboot flash super super.img_sparsechunk.12 fastboot flash super super.img_sparsechunk.13 fastboot flash super super.img_sparsechunk.14 fastboot flash super super.img_sparsechunk.15 fastboot flash dsp dspso.bin fastboot flash erase userdata fastboot flash erase ddr fastboot oem fb_mode_clear
- Now your device will reboot into bootloader with the firmware you installed.
That’s it, guys. We hope this guide was helpful to you. Feel free to ask in the comment below for additional queries.
