How to Install Stock ROM on Motorola One XT1941-4 (Firmware Guide)

Want to install the stock firmware on your Motorola One? then you are in the right place. In this guide, we will help you in installing the official stock firmware on Motorola One (codenamed deen) variant XT1941-4. Stock firmware comes in handy when you mess up your device to root it or install a mod or custom ROM. To be on the safe side, we always ask our users to download the official firmware on their PC and save it.

By installing firmware flash file on Motorola One XT1941-4, you can unbrick, restore, fix any software related issue, downgrade or upgrade, resolve any bugs or lag on your device. To install the Motorola One XT1941-4 firmware, you need the ADB and Fastboot tool on your computer.

How to Install Stock ROM on Motorola One XT1941-4 (Firmware Guide)

Motorola XT1941-4 Firmware Flash Files:

Flash File Name: QPKS30.54-22-13-13
Model: XT1941-4 | RETEU | Europe
Android Version: 10
Download
Flash File Name: QPKS30.54-22-13-12
Model: XT1941-4 | RETEU | Europe
Android Version: 10
Download
Flash File Name: QPKS30.54-22-13-13
Model:
XT1941-4 | RETIN | India
Android Version:
10
Download
Flash File Name: QPKS30.54-22-13-4
Model:
XT1941-4 | RETIN | India
Android Version:
10
Download

Steps to Install Motorola XT1941-4 Firmware Flash File

If you have downloaded the firmware, then follow this guide to flash the stock firmware manually on your Motorola One XT1941-4. Make sure to follow the steps carefully.

Pre-Requirements:

Disclaimer:

GetDroidTips will not be held responsible for any kind of hardware or software damage to your device by following this guide. Proceed at your own risk

Firmware Installation Guide:

Check out the firmware flashing guide below for the Motorola One XT1941-4. First, make sure to install or extract the adb and fastboot tool on your PC. Now enter the bootloader on your device.

bootloader mode

Step 1. Bootloader Mode

Enter bootloader mode on your phone. To boot first, turn your phone off. Once your device turned off completely, press and hold volume down, and turn it on. You should see the bootloader screen.

Step 2. Connect Your Device to PC:

After booting your Motorola One into bootloader mode, now connect it to the PC using the USB Cable.

Step 3. Download Stock ROM/Firmware:

To get the full ROM, you can use the LMSA or Rescue and Smart Assistant Tool. Download the zip file and copy it to somewhere on your PC. LMSA tool will unzip the file and will remove the zip file you downloaded.

device rescue Motorola Rescue and Smart Assistant Tool

Advertisements

You can also download the full stock ROM from the above download flash file section on this guide.

Step 4. Flashing Guide:

  1. The next step is to open the command window and go to the adb folder Open Command Window here
  2. Enter the following command to flash the firmware.
    fastboot oem fb_mode_set
    fastboot flash partition gpt.bin
    fastboot flash bootloader bootloader.img
    fastboot flash vbmeta vbmeta.img
    fastboot flash radio radio.img
    fastboot flash logo logo.bin
    fastboot flash boot boot.img
    fastboot flash dtbo dtbo.img
    fastboot flash recovery recovery.img
    fastboot flash super super.img_sparsechunk.0
    fastboot flash super super.img_sparsechunk.1
    fastboot flash super super.img_sparsechunk.2
    fastboot flash super super.img_sparsechunk.3
    fastboot flash super super.img_sparsechunk.4
    fastboot flash super super.img_sparsechunk.5
    fastboot flash super super.img_sparsechunk.6
    fastboot flash super super.img_sparsechunk.7
    fastboot flash super super.img_sparsechunk.8
    fastboot flash super super.img_sparsechunk.9
    fastboot flash super super.img_sparsechunk.10
    fastboot flash super super.img_sparsechunk.11
    fastboot flash super super.img_sparsechunk.12
    fastboot flash super super.img_sparsechunk.13
    fastboot flash super super.img_sparsechunk.14
    fastboot flash super super.img_sparsechunk.15
    fastboot flash dsp dspso.bin
    fastboot flash erase userdata
    fastboot flash erase ddr
    fastboot oem fb_mode_clear
  3. Now your device will reboot into bootloader with the firmware you installed.

That’s it, guys. We hope this guide was helpful to you. Feel free to ask in the comment below for additional queries.
