How to Root POCO X3 GT (chopin) using Magisk without TWRP

If you’re using the Xiaomi POCO X3 GT (chopin) device and want to enable root access via Magisk, then this guide is for you. In this guide, we have shared the steps to Root POCO X3 GT using Magisk without TWRP in a very simple way for your ease.

In order to root your Xiaomi POCO X3 GT, we will use the Magisk to patch the stock boot image and flash that to your device’s boot partition. Now, if you ask why Magisk? It’s a system-less root process that doesn’t tamper with the system partitions while enabling root access. Magisk can also hide online security measures to work apps properly like any banking app, SafetyNet, etc.

How to Root POCO X3 GT (chopin) using Magisk without TWRP

Poco X3 GT Device Overview:

The Poco X3 GT features a 6.6-inch IPS LCD panel with a resolution of 1080 x 2400 pixels and an aspect ratio of 20:9. It is a high refresh rate panel with a refresh rate of 120Hz. It supports HDR10 content and is protected by Corning Gorilla Glass Victus. Under the hood, we have the MediaTek Dimensity 1100 5G chip built on a 6nm manufacturing process. It is an octa-core processor with four Cortex-A78 cores clocked at 2.6 GHz and four Cortex-A55 cores clocked at 2.0 GHz. For handling the graphics-intensive tasks, we have the Mali-G77 MC9.

Regarding optics, we have a triple camera setup at the rear and a single camera setup at the front. The triple camera setup at the rear features a 64MP primary sensor paired with an f/1.8 lens, an 8MP ultrawide sensor paired with an f/2.2 lens, and a 2MP macro sensor paired with an f/2.4 lens. At the front, we get a single 16MP sensor paired with an f/2.5 lens. The rear camera setup can do a 4K recording, but the front setup is limited to 1080p recording.

Advertisements

The Poco X3 GT comes in three storage options: 128GB internal storage + 6GB RAM, 128GB internal storage + 8GB RAM, and 256GB internal storage + 8GB RAM. It will run on Android 11 out of the box with MIUI 12.5 skin on top. For communications, we have Wi-Fi 802.11 a/b/g/n/ac/6, Bluetooth 5.2, GPS, NFC, and USB Type-C 2.0. And for sensors, we have a side-mounted fingerprint sensor, accelerometer, gyro, proximity, and compass. The battery inside the smartphone is a 5,000 mAh cell that supports 67W fast charging. The company claims that the smartphone goes from 0 to 100% in 42 min. The smartphone will be available in three color options: Gray, Blue/Green, and White.

Steps To Root POCO X3 GT (chopin) Using Magisk

Follow the full-depth guide along with the requirements and download links below.

Keep in mind:

  • Rooting may void the manufacturer’s warranty on your device.
  • Rooting will block the firmware OTA updates.

Now, let’s head over to some of the necessary steps which you need to abide by:

Advertisements

Pre-Requirements

  • You need to unlock the bootloader on your POCO X3 GT
  • Your phone should have a battery juice of more than 60% at least.
  • Keep a backup of your device data at first. Therefore, if anything goes wrong, you can get back the important data.
  • The image file in this article is supported by the POCO X3 GT (chopin) model only. DO NOT try to flash it on other models.
  • You will also require a PC/Laptop and a USB cable in order to connect your device with the computer.
  • You should download all the necessary files, tools, and drivers from below accordingly.

Required Downloads:

Warning:

We’re at GetDroidTips won’t be responsible for any kind of error or damage that occurs to your phone during or after following this guide or flashing any file. You should know what you’re doing. Take a full backup at first and proceed at your own risk!

1. How to Extract and Patch Boot.image using Magisk?

  • First of all, download and extract the ROM to your PC.
  • Attach your device via USB cable and copy only the boot.img file from the extracted folder to your device storage
  • Launch Magisk Manager. When a popup appears asking to install Magisk, select INSTALL and choose install again.
  • Tap on “Patch Boot Image File”.
    Install patched boot image TWRP
  • Navigate to internal storage and select your phone’s boot image that you transferred earlier.
  • Wait for a couple of seconds. Magisk will start patching the boot image.
  • Once the boot image has been patched, copy the “patched_boot.img” from the internal storage and replace it in the same extracted ROM folder on your PC.

Now you can follow the second step to flash the patched boot image file.

2. Steps To Install the Patched Boot Image on POCO X3 GT

Follow the proper guide to install Patched Boot Image on POCO X3 GT from the below link:

  • Now, extract the ADB & Fastboot tool, then move the patched boot image file to the same folder.
  • Press and hold down the Shift key + right-mouse-click to open the command window/PowerShell.
  • Next, enter the following command in order to flash the “patched_boot.img” to install Magisk and root your Android device:
fastboot flash boot patched_boot.img
  • For devices with an A/B partition system, you have to use the following commands:
fastboot flash boot_a patched_boot.img

fastboot flash boot_b patched_boot.img

Please replace [patched_boot.img] with the name of the boot image file you downloaded followed by the .img extension.

Advertisements
  • Wait for the flashing process to complete.
  • Finally, type in the command to reboot your device.
fastboot reboot
  • That’s it.

Steps to Verify the Systemless Root

  1. Launch the Magisk Manager app on your device.
  2. Now, in order to verify the systemless root access on your phone, you will see the status screen. Here all options should be green ticked if properly rooted. If yes, that means you’ve successfully bypassed the Google SafetyNet measure as well.Magisk Status Check

Advertisement

That’s it, guys. We hope that you’ve found this guide useful and have successfully rooted your POCO X3 GT (chopin) device. For any queries, feel free to ask in the comments below.
