How to Root Moto G50 XT2137 / XT2145 using Magisk without TWRP

In this guide, we have shared with you the steps to Root Moto G50 (model: XT2137 / XT2145, codenamed ibiza) using Magisk without TWRP in a very simple way for your ease.

In order to root your Moto G50, we will use the Magisk to patch the stock boot image and flash that to your device boot partition. Now, if you ask why Magisk? It’s a system-less root process that doesn’t tamper with the system partitions while enabling root access. Magisk can also hide online security measures to work apps properly like any banking app, SafetyNet, etc.

Steps To Root Moto G50 XT2137 / XT2145 Using Magisk

Follow the full-depth guide along with the requirements and download links below.

Keep in mind:

To root, your device bootloader must be unlocked.
Rooting may void the manufacturer’s warranty on your device.
Rooting will block the firmware OTA updates.

Now, let’s head over to some of the necessary steps which you need to abide by:

Pre-Requirements

Your phone should have a battery juice of more than 60% at least.
Keep a backup of your device data at first. Therefore, if anything goes wrong, you can get back the important data.
The image file in this article is supported by the Moto G50 model only. DO NOT try to flash it on other models.
You will also require a PC/Laptop and a USB cable in order to connect your device with the computer.
You should download all the necessary files, tools, and drivers from below accordingly.

Required Downloads:

Download ADB & Fastboot files (Windows/MAC)
Motorola USB Drivers – Download and install it on your computer
Download the latest Moto G50 Firmware Flash File and move it to the PC

Warning:

We’re at GetDroidTips won’t be responsible for any kind of error or damage that occurs to your phone during or after following this guide or flashing any file. You should know what you’re doing. Take a full backup at first and proceed at your own risk!

1. How to Extract and Patch Boot.image using Magisk?

First of all, download and extract the ROM to your PC.
Attach your device via USB cable and copy only the boot.img file from the extracted folder to your device storage
Launch Magisk Manager. When a popup appears asking to install Magisk, select INSTALL and choose install again.
Tap on “Patch Boot Image File”.
Navigate to internal storage and select your phone’s boot image that you transferred earlier.
Wait for a couple of seconds. Magisk will start patching the boot image.
Once the boot image has been patched, copy the “patched_boot.img” from the internal storage and replace it in the same extracted ROM folder on your PC.

Now you can follow the second step to flash the patched boot image file.

2. Steps To Install the Patched Boot Image on Moto G50

Follow the proper guide to install Patched Boot Image on Moto G50 from the below link:

Now, extract the ADB & Fastboot tool, then move the patched boot image file to the same folder.
Press and hold down the Shift key + right-mouse-click to open the command window/PowerShell.
Next, enter the following command in order to flash the “patched_boot.img” to install Magisk and root your Android device:

fastboot flash boot patched_boot.img

For devices with an A/B partition system, you have to use the following commands:

fastboot flash boot_a patched_boot.img

fastboot flash boot_b patched_boot.img

Please replace [patched_boot.img] with the name of the boot image file you downloaded followed by the .img extension.

Wait for the flashing process to complete.
Finally, type in the command to reboot your device.

fastboot reboot

That’s it.
