How to Install Official TWRP Recovery on Motorola Moto G5 Plus and Root it

Updated on October 12, 2020 by Abd Razaaq

Advertisements

Motorola Moto G5 Plus (codename: potter) was launched in the year February 2017. The phone came out of the box with Android 7.0 Nougat and later upgraded to Android 8.0 Oreo. Recently this device has received the official TWRP recovery support. So, on this page, we will guide you to install the TWRP Recovery on Moto G5 Plus. This guide contains both the written instruction and video tutorial to help you install it quickly. Make sure to download the files required and then jump straight into instruction on how to install TWRP Recovery and Root your Moto G5 Plus.

Keep in mind that before heading over to the process, you will need to unlock the device bootloader at first. As the smartphone OEMs provide a locked bootloader to its devices due to some security concerns, in order to install any third-party file, you will need to unlock the bootloader. Then you will be capable to install TWRP Custom Recovery on your Moto G5 Plus device and root as well. The TWRP Recovery can also take Nandroid backups, restore, wipe out system/data/cache, and more.

How to Install Official TWRP Recovery on Moto G5 Plus and Root it

Related Post
  • Download and Install Lineage OS 17.1 for Motorola Moto G5 Plus based on Android 10 Q
  • List of Best Custom ROM for Moto G5 Plus (potter)
  • Download and Install AOSP Android 10 Q for Moto G5 Plus
  • Motorola Moto G5 Plus Stock Firmware Collections

Table of Contents

  • 1 TWRP Recovery and its Advantages
  • 2 Advantages of TWRP Recovery:
  • 3 How to Install Official TWRP Recovery on Moto G5 Plus (potter)
    • 3.1 Pre-Requirements:
    • 3.2 TWRP Recovery Details
    • 3.3 Method: ADB and Fastboot Tool
  • 4 What is Root?
    • 4.1 The advantage of Rooting:
    • 4.2 Steps to Root Moto G5 Plus

TWRP Recovery and its Advantages

Team Win Recovery Project is an open-source software custom recovery image for Android-based devices. It provides a touchscreen-enabled interface that allows users to install third-party firmware and back up the current system which is functions often unsupported by stock recovery images. – WikiPedia

Advantages of TWRP Recovery:

  • You can flash Custom ROM on Moto G5 Plus using TWRP
  • You can flash modding zip files to customize your phone
  • Easy to flash and use Xposed Modules using TWRP
  • Easy to Root and Unroot using TWRP Recovery flashable zip SuperSU
  • You can install Magisk on Moto G5 Plus
  • Easy to Create and Restore Nandroid Backup using TWRP Recovery.
  • Easy access to restore the Nandroid Backup.
  • You can flash the image file using TWRP Recovery on Moto G5 Plus
  • Easy to remove all bloatware using TWRP Recovery on Moto G5 Plus.
  • To underclock and overclock.
  • You can clean Wipe, Cache, and Data.

How to Install Official TWRP Recovery on Moto G5 Plus (potter)

Before going to the TWRP installation process, make sure to follow all the pre-requirements mentioned below properly.

Advertisements

Pre-Requirements:

  • The file and guide are supported for the Moto G5 Plus (potter) model only. Don’t try it on other devices.
  • Moto G5 Plus bootloader should be unlocked.
  • A PC/Laptop and a USB cable are required for this process.
  • Make sure to take a Full Backup of Device Data (No Root).
  • Charge your device battery to full.
  • Download All Required Files:
    • No Verity opt Encrypt
    • Download SuperSU Zip – For root using SuperSU
    • Download Magisk Zip – For root using Magisk
    • USB Drivers: Motorola USB Drivers
    • Download ADB and Fastboot and install it on your PC

TWRP Recovery Details

File Name TWRP Recovery
Version V3.4.0 and Higher
Support Official
Developer TWRP Team
Download Link Download

Disclaimer:

GetDroidTips will not be responsible for any kind of damage or error that occurs to your device while/after installing the files or following this guide. Make sure to take a complete backup before doing anything. Do this at your own risk.

Method: ADB and Fastboot Tool

After downloading all the required files, drivers, and tools, follow the installation process.

  • First of all, enable the Developer Options and USB Debugging mode on your device.
  • Head over to the device Settings > System > About Phone > then tap on the Build Number for seven times to enable Developer options mode.
  • Now, go to the Developer options in the Settings menu and turn on the toggle to enable USB debugging.
  • Next, open the ADB & Fastboot folder on your computer. Then press and hold the Shift key and right mouse click to open the command window.adb command window
  • Turn off your device > Press and hold the Volume Up + Power button together for a few seconds to enter into Fastboot mode.
  • Connect your device with the PC via a USB cable and type the following code on the command windows and hit enter:
adb reboot bootloader
  • Now, your device is connected successfully as a fastboot device.
  • Type the following command and hit enter to check the fastboot device connected or not:
fastboot devices
  • Now, in order to install TWRP Recovery on your phone, type the following command and press enter:
fastboot flash recovery twrpname.img
  • To just boot, you can use the command fastboot boot twrpname.img
  • That’s it. You’ve successfully installed the TWRP Recovery on the Moto G5 Plus device. Now, you have to flash the Root.

What is Root?

Smartphone Rooting is the unofficial way to enable an administrator or superuser access to your device system and subsystem. Therefore, the user can easily tweak, change, edit, or delete system files and apps easily.

With the help of rooting, you can uninstall bloatware, increase device performance, reduce battery draining, install Xposed modules, and more. However, smartphone rooting will void the device warranty and you may not get software OTA updates anymore. Improper way of rooting can also brick your device easily. Therefore, make sure to follow the guide properly.

Advertisements

The advantage of Rooting:

  • You can get access to all files on your Moto G5 Plus, even the files which present in the root directory of your phone.
  • You can increase the performance of your Moto G5 Plus by overclocking.
  • By rooting you can increase battery life by underclocking Moto G5 Plus.
  • Uninstall Bloatware on Moto G5 Plus.
  • You can block Ads on any Android applications such as Youtube and other game-related applications.

Also Read: Top 5 Adblock Plus Alternatives for Android

  • By Rooting Moto G5 Plus, you can View, Edit, or Delete any system file inside the root directory.
  • You can install the Xposed Framework and many Xposed module support.

Steps to Root Moto G5 Plus

Guide to Root Moto G5 Plus via SuperSU

Guide to Root Moto G5 Plus via Magisk

We assume that this full-depth installation guide will be helpful to you. For any queries, feel free to ask in the comments below.
